Full Gigabit Speeds For UHD Streaming
With advanced HomePlug AV2 technology, PH3 provides you with stable, high-speed data transfer rates of up to 1000Mbps on the powerline, and integration Gigabit Ethernet ports for wired devices bring you full Gigabit network; Perfect support 4K HD video smooth online play, At the same whether it is a multimedia player, online games, PH3 can provide fast Internet experience

Accessible wall, Internet signal transfer while the powerline exist
Powerline technology allows existing wires become vector transmission of multimedia and data flow,you can access to the internet where the socket exist,easy to get home, office network expansion and extension

Election materials, safe and reliable
Rigorous work, excellent choice of materials is PH3 transmission stable, reliable and durable basis,effective transmission distance up to 300 meters
• Broadcom Gigabit Powerline chips • V0 class fire retardant housing • Innovative board design process

Plug and play, easy networking
The factory default pairing, plug in the socket to finish the networking automatically, no need to set, saving time

Intelligent power-saving, environmental protection
PH3 Low-power consumption design, full load power consumption less than 3.2W,
built in the latest intelligent detection function, when no device connects to PH3,it will switch to standby mode, the power will automatically switch from normal mode to 0.36W power saving mode, you can save up to 88% power consumption.

Interfaces: 2 * 10/100/1000 Mbps RJ45
Button: 1 * Pair/Reset
LED Indicator: 1 * Power, 1 * Powerline, 1 * Ethernet
Power Input: AC100~240V 50/60Hz 0.1A
Power Consumption: 3.2W(220V/50Hz) Maximum
Dimension: 82mm*60mm*32mm(L x W x H)
Wireless Standard: HomeplugAV2
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Frequency: 2-86MHz
Data Rate: 1000Mbps
Certification: CE, FCC?RoHS
Plug Type: US?EU?UK
Package Contents:
2 * AV1000 Gigabit Powerline Adapter
1 * Quick Installation Guide
2* Cat5e Ethernet Cable
Environment
Operating Temperature: 0°C ~ 40°C(32°F ~ 104°F)
Storage Temperature: -40°F ~ 158°F (-40°C ~ 70°C )
Operating Humidity: 10% ~ 90% RH non-condensing
Storage Humidity: 5% ~ 90%RH non-condensing
Related Products: PH5?PH6?PH10
